Power Probe PPEVTEST Multimeter for EV Repair and Maintenance

Three testers. One EV-ready tool

The Power Probe PPEVTEST is a professional electrical safety tester built for electric and hybrid vehicle diagnostics. It replaces a CAT III 1000V/CAT IV 600V True RMS voltmeter, a 1kV insulation resistance tester and a true milliohm meter in one handheld unit, so a technician can check voltage, insulation integrity and bonding resistance on high-voltage EV systems without switching tools.

Features and Functions

Replaces a CAT III 1000V/CAT IV 600V True RMS voltmeter, a 1kV insulation tester and a true milliohm meter in one instrument.
Insulation resistance up to 1000VDC and 200GΩ, with Polarization Index, Dielectric Absorption Ratio and countdown timer calculations.
4-wire Kelvin resistance from 0.001mΩ for bonding and low-resistance checks; 2-wire mode covers up to 40.00kΩ.
Smart diode test automatically detects polarity, or run the traditional positive-only Classic mode.
Wire length calculator works out cable length from AWG and measured resistance, up to 10km.
Capacitance up to 1000µF and temperature from -40°C to 400°C via the included K-type thermocouple.
Bluetooth 5.0 connects to the Power Probe Link app for remote monitoring, storing up to 400 test results with auto-save.
2.8in backlit TFT colour display with bar-graph scale and a PASS/FAIL compare indicator against user-set thresholds.

P/No. : ppevtest

Technical Specifications

Voltage	True RMS AC/DC, up to 1000V, CAT III 1000V / CAT IV 600V
Resistance, 2-wire	0.01Ω – 40.00kΩ
Resistance, 4-wire Kelvin	0.001mΩ – 40.00Ω
Insulation resistance	Up to 1000VDC, 200GΩ, with PI / DAR / Timer
Capacitance	100.0nF – 1000µF
Temperature	-40°C to 400°C / -40°F to 752°F
Display	2.8in backlit TFT colour, 4000 counts
Bluetooth	BLE 5.0, 6m+ range, Power Probe Link app
Data storage	Up to 400 test results
Power	4 × 1.5V AA alkaline batteries
Dimensions / weight	96 x 207 x 54mm with holster / 630g including battery

What's in the box?

1× Power Probe PPEVTEST Electrical Safety Tester
Alligator Clip Set
CAT III 1000V/CAT IV 600V Threaded Test Leads
Kelvin 4-Wire CLIP4W Test Leads
ISOPROBE Test Leads · K-Type Thermocouple
Magnet Strap
User Manual
Protective Carrying Case
