Power Probe PPAMPTIP Amp Adapter Tip for Power Probe 3, 3EZ, 4, Maestro and Basic

See the current. Find the drain.

The Power Probe PPAMP Amp Adapter is a plug-in adapter tip that turns a compatible Power Probe circuit tester into an inline DC current meter. Read live current on its backlit LCD from as low as 1mA up to a 20A display, with MIN and MAX held in memory to catch spikes and intermittent draws. It is the tip to reach for when the question is how much a circuit is really pulling, from a parasitic key-off drain to a full load.

Features and Functions

Inline DC current meter: plugs into the 4mm banana tip of a compatible Power Probe circuit tester and reads live current draw
Wide range from 1mA up to a 20.0A display value, with a 10A maximum input, for parasitic drains and larger load currents
MIN and MAX values held in memory to catch current spikes and intermittent draws, cleared from the button
Backlit LCD with an auto-on backlight in low light, plus a battery-status symbol on the display
Auto-shutdown after about 10 minutes of no use to preserve the CR2032 battery
DC-only, auto-ranging meter (no True RMS) for 12V automotive circuits; over-range shows OL
Battery included

£52.95 + VAT

P/No. : ppamptip

Technical Specifications

Function	Inline DC current (auto-range, no True RMS)
Range 1	0mA - 999mA, resolution 1mA
Range 2	1.00A - 9.99A, resolution 0.01A
Accuracy	±(3% + 3d)
Maximum display	20.0A
Maximum input current	10A DC
Over-range	OL
Display	Backlit LCD with MIN / MAX memory
Auto-shutdown	About 10 minutes
Power	1 x CR2032 3V (included)
Standards	UL 61010-1 / 61010-2-030, CSA C22.2, CE
Compatibility	Power Probe III, IV, Master, ECT3000 (4mm banana tip)
Dimensions / weight	44 x 89 x 21mm / about 38.5g
Warranty	2 years limited

Call us now on01823 328500 for more details
